API-5CT OCTG Casing Pipe

Home > steelpipe1

API-5CT OCTG Casing Pipe

Steel grade: J55, K55, L80, N80, C95, P110

O. D. Range Tubing: From 2-3/8"to 4-1/2"(EUE/NU)

Casing: From 4-1/2" to 20",

Threads: BTC, LTC, STC.

Length range: R1, R2, R3

OD mm	Ib/ft	Grade	W.T	short	long	buttress
114.30(4 1/2")	9.50	H,J,K	5.21	YES
	10.50	J,K	5.69	YES		YES
	11.60	J,K,C,L,N,P	6.35	YES	YES	YES
	13.50	C,L,N,P	7.37		YES	YES
	15.10	P,Q	8.56		YES	YES
127.00(5")	11.50	J,K	5.59	YES
	13.00	J,K	6.43	YES	YES	YES
	15.00	J,K,C,L,N,P	7.52	YES	YES	YES
	18.00	C,L,N,P,Q	9.19		YES	YES
	21.40	C,L,N,P,Q	11.10		YES	YES
	23.20	C,L,N,P,Q	12.14		YES	YES
	24.10	C,L,N,P,Q	12.70		YES	YES
139.70(5 1/2")	14.00	H,J,K	6.20	YES
	15.50	J,K	6.98	YES	YES	YES
	17.00	J,K,C,L,N,P	7.72	YES	YES	YES
	20.00	C,L,N,P	9.17		YES	YES
	23.00	C,L,N,P,Q	10.54		YES	YES
168.28(6 5/8")	20.00	H,J,K	7.32	YES	YES	YES
	24.00	J,K,C,L,N,P	8.94	YES	YES	YES
	28.00	C,L,N,P	10.59		YES	YES
	32.00	C,L,N,P,Q	12.06		YES	YES
177.80(7")	20.00	H,J,K	6.91	YES
	23.00	J,K,C,L,N	8.05	YES	YES	YES
	26.00	J,K,C,L,N,P	9.19	YES	YES	YES
	29.00	C,L,N,P	10.36		YES	YES
	32.00	C,L,N,P	11.51		YES	YES
	35.00	C,L,N,P,Q	12.65		YES	YES
	38.00	C,L,N,P,Q	13.72		YES	YES
193.68(7 5/8")	24.00	H	7.62	YES
	26.40	J,K,C,L,N	8.33	YES	YES	YES
	29.70	C,L,N,P	9.52		YES	YES
	33.70	C,L,N,P	10.92		YES	YES
	39.00	C,L,N,P,Q	12.70		YES	YES
	42.80	C,L,N,P,Q	14.27		YES	YES
	45.30	C,L,N,P,Q	15.11		YES	YES
	47.10	C,L,N,P,Q	15.88		YES	YES
196.85(7 3/4")	46.10	C,L,N,P,Q	15.11
219.08(8 5/8")	24.00	J,K	6.71	YES
	28.00	H	7.72	YES
	32.00	H,J,K	8.94	YES	YES	YES
	36.00	J,K,C,L,N	10.16	YES	YES	YES
	40.00	C,L,N,P	11.43		YES	YES
	44.00	C,L,N,P	12.70		YES	YES
	49.00	C,L,N,P,Q	14.15		YES	YES
244.48(9 5/8")	32.30	H	7.92	YES
	36.00	H,J,K	8.94	YES	YES	YES
	40.00	J,K,C,L,N	10.03		YES	YES
	43.50	C,L,N,P	11.05		YES	YES
	47.00	C,L,N,P,Q	11.99		YES	YES
	53.50	C,L,N,P,Q	13.84		YES	YES
273.05(10 3/4")	32.75	H	7.09	YES
	40.50	H,J,K	8.89	YES		YES
	45.50	J,K	10.16	YES		YES
	51.00	J,K,C,L,N,P	11.43	YES		YES
	55.50	C,L,N,P	12.57	YES		YES
	60.70	P,Q	13.84	YES		YES
	65.70	P,Q	15.11	YES		YES
298.45(11 3/4")	42.00	H	8.46	YES
	47.00	J,K,M	9.53	YES		YES
	54.00	J,K,M	11.05	YES		YES
	60.00	J,K,M,L,N,C,P,Q	12.42	YES		YES
339.7(13 3/8")	48.00	H	8.38	YES
	54.50	J,K	9.65	YES		YES
	61.00	J,K	10.92	YES		YES
	68.00	J,K,C,L,N,P	12.19	YES		YES
	72.00	C,L,N,P,Q	13.06	YES		YES
406.40(16")	65.00	H	9.53	YES
	75.00	J,K,M	11.13	YES		YES
	84.00	J,K,M	12.57	YES		YES
473.08(18 5/8")	87.50	H,J,K,M	11.05	YES	YES	YES
508.00(20")	94.00	H,J,K	11.13	YES	YES	YES
	106.50	J,K	12.70	YES	YES	YES
	133.00	J,K	16.13	YES	YES	YES
