carbon steel pipe Cold Drawn pipe
1.O.D.:13.70-609.60mm
2.W.T.: 1.50-59.51mm
3.Length:3.0-11.8m
4.good mechanical property
SEAMLESS STEEL PIPE
|
Product Name |
Steel Pipe |
| Size | O.D.:1/4"-24" |
| W.T.:0.057"-2.34" | |
| Length:5.8-11.8m or according to your needs | |
| Steel Grade | Q195,Q235,16Mn,20#,45#(Chinese Standard, Other Material Can Also Be Provided),A53B,A106B |
| Standard | ASTM, ASME, DIN,GB,JIS,ASNI,BS |
| Usage | Structure, Automotive,Machinery,Airport, Railway And Construction and so on. |
| Ends | P.E or B.E |
| Surface | As per the requirement of customers |
| Technique | ERW ,Hot Rolled and Cold Drawn |
| Certification | ISO9001, API |
| Package | In Bundle or In Bulk, Containers Or According to Clients' Requirements |
| Date of Delivery | Less than 15/20/25/30/40/50/60 days depend on the quantity |
| Notes |
| Chemical Composition % | Mechanical Properties | ||||||||||||
| Steel Grade | C | Si | Mn | P | S | Cr | Mo | Ni | Cu | V | Elongation % | Yield Strength Mpa | Tensile Strength Mpa |
| ASTM A53 A | ≤0.25 | / | ≤0.95 | ≤0.05 | ≤0.06 | ≤0.04 | ≤0.15 | ≤0.40 | ≤0.04 | ≤0.08 | ≥29.5 | ≥205 | ≥330 |
| ASTM A53 B | ≤0.30 | / | ≤1.2 | ≤0.05 | ≤0.06 | ≤0.04 | ≤0.15 | ≤0.40 | ≤0.04 | ≤0.08 | ≥29.5 | ≥240 | ≥415 |
| ASTM A106 B | ≤0.30 | ≤0.10 | 0.29-1.06 | ≤0.035 | ≤0.035 | ≤0.04 | ≤0.15 | ≤0.40 | ≤0.04 | ≤0.08 | ≥30 | ≥240 | ≥415 |
| ASTM A106 C | ≤0.30 | ≤0.10 | 0.29-1.06 | ≤0.035 | ≤0.035 | ≤0.04 | ≤0.15 | ≤0.40 | ≤0.04 | ≤0.08 | ≥30 | ≥275 | ≥485 |
| 20 | 0.17-0.24 | 0.17-0.37 | 0.35-0.65 | ≤0.035 | ≤0.035 | ≤0.25 | / | ≤0.25 | ≤0.25 | / | ≥20 | ≥245 | ≥410 |
| 45 | 0.42-0.50 | 0.17-0.37 | 0.50-0.80 | ≤0.035 | ≤0.035 | ≤0.25 | / | ≤0.25 | ≤0.25 | ≥16 | ≥355 | ≥600 | |
| 20G | 0.17-0.24 | 0.17-0.37 | 0.35-0.65 | ≤0.030 | ≤0.030 | 0.80-1.10 | 0.40-0.55 | ≤0.25 | ≥25 | ≥250 | ≥420 | ||
Seamless steel pipe has outstanding homogeneity in the circumferential direction and is thus highly resistant to internal pressure and torsion.
Taking advantage of this feature, its widely used for transmission of petroleum, natural gas, drilling, pumping and other fluids.
Products include over a hundred specifications for the various applications in regular, pressure, submarine, low-temperature, high-temperature corrosion-resistant and other pipelines.
