Mechanical properties according to EN 10025:2004 and old European standards comparable.Other steel grades are available upon request.
|
Reference standard: EN 10025:2004 |
Former designations | |||||||
|---|---|---|---|---|---|---|---|---|
| Shade | Minimum yield strength R eH | Tensile strength R m |
Minimum elongation |
F | D | GB | B | |
| N / mm 2 | N / mm 2 | % | NF A 35-501 | DIN 17100 | BS 4360 |
NBN A21-101 |
||
|
Thickness (mm) |
Thickness (mm) | Thickness (mm) | ||||||
 16 |
> 16 40 |
 3 100 |
3 40 |
|||||
| S 235 JRG2 | 235 | 225 | 340-470 | 26 | RSt 37-2 | 40 B | ||
| S 235 J0 | 235 | 225 | 340-470 | 26 | E 24-3 | St 37-3 U | 40 C | AE 235-C |
| S 275 JR | 275 | 265 | 410-560 | 22 | E 28-2 | St 44-2 | 43 B | AE 255-B |
| S 275 J0 | 275 | 265 | 410-560 | 22 | E 28-3 | St 44-3 U | 43 C | AE 255-C |
| S 355 JR | 355 | 345 | 490-630 | 22 | E 36-2 | 50 B | AE 355-B | |
| S 355 J0 | 355 | 345 | 490-630 | 22 | E 36-3 | St 52-3 U | 50 C | AE 355-C |
| S 355 J2G3/G4 | 355 | 345 | 490-630 | 22 | St 52-3 N | 50 D | AE 355-D | |
