One of the Top 500 enterprises in China foreign trade
QCCO was approved as a member of “China Association for Contracting Projects Abroad “and granted a membership certificate on Sep 28,2005; “Credibility Rating AAA certificate in Foreign Trade” was granted to QCCO by China Shippers’ Association
1. Grade: SAE 1020, 16Mn, Q235, ST52
2. OD: 20-89mm
3. WT: 4.6-7.2mm
Seamless pipe SCH40/SCH80/SCH60/SCH160/
1.Material:A106/A53/Q345B,Etc.
2.Size:1/2",3/4",11/2",3",4",6",8",10"
3.Bundle,black coating
|
Usage: |
used for gas, oil, water pipes and construction |
|
|
Ends: |
plain ends or threaded with socket and plastic caps or beveled ends |
|
|
Surface: |
bared or black painted, galvanized or with oiled or client option |
|
|
Products |
Small Diameter Cold Drawn Seamless Steel Pipe |
|||||||||
|
Origin |
cagnzhou, China |
|||||||||
|
Standards |
GB 8162/GB 8163 |
|||||||||
|
Grades |
sae 1020, 20#, 45#, 16Mn |
|||||||||
|
Chemical Composition (%) |
C |
Si |
Mn |
Cr |
Ni |
Cu |
||||
|
≤ |
||||||||||
|
0.17-0.23 |
0.17-0.37 |
0.35 |
0.35 |
0.30 |
0.25 |
|||||
|
Physical properties |
Tensile Strength(MPa) 233-500 Elongation ≥ 24% |
|||||||||
|
Process Methods |
Cold Drawn |
|||||||||
|
Shapes |
Round |
Square |
Hexagon |
Octagon |
||||||
|
Sizes |
Outer Diameter(OD) |
20mm-22mm |
25mm-28mm |
30mm-36mm |
38mm-89mm |
|||||
|
Wall Thickness(WT) |
4.6mm-7.2mm |
|||||||||
|
Length |
5.8m, 8m, 12m or at random |
|||||||||
|
We can also supply Non-Standard pipes/tubes |
||||||||||
|
Application Range |
Steel pipe is an alloy of iron and carbon, with the proportion of carbon having a large influence on the properties of the steel. The carbon content of the steel and steel sheet can be anything from 0.08% to 2.00%. Mild steel is sometimes referred to as carbon steel or plain steel. |
|||||||||
|
Packing |
Standard seaworthy packing(NB: Coating against rust) |
|||||||||
|
Minimum Order Quantity |
5 Metric Ton for SMLS |
|||||||||
|
Terms Of Payment |
T/T in advance or irrevocable L/C at sight |
|||||||||
|
Delivery Conditions |
TINJIN |
|||||||||
|
Delivery Time |
Min 15 days After Received the Payments |
|||||||||
