One of the Top 500 enterprises in China foreign trade
QCCO was approved as a member of “China Association for Contracting Projects Abroad “and granted a membership certificate on Sep 28,2005; “Credibility Rating AAA certificate in Foreign Trade” was granted to QCCO by China Shippers’ Association
1. Product describe
Outer Diameter: 21.3mm-630mm
Well Thickness: 1.8mm-22.2mm
Our All Materials Grade: welding steel pipe|
ASTM A53: Gr. A B,
API A, B, J55, K55, X42, X46, X52, X56, X60 X65, X70 X80
GB/T3091, 9711: Q195, Q215, Q235, Q345, etc. Drill pipe|
EN10217: P195TR1, P195TR2, P235TR1, P235TR2, P265TR1, P265TR2, P195GH, P235GH, P265GH, 16Mo3
EN10219: S235JRH, S235J0H, S235J2H, S355J0H, S355J2H, S355K2H, S275JR
DIN17100: ST52-3 ST44-2 ST37-2 etc
Standard: EN10219
External Coating: 3PE
Production Capacity: 200, 000 tons/year
Application: Petroleum. Natural gas, coal gas distribution, tubing and
Casing, construction, heating, power, piles field. Steel pipe |
2. Trade Item
Certificate: ISO9001-2000, API 5L/5CT, SGS
Minimum Quantity: 10ton
Delivery Time: Usually 25-30days
Payment Terms: 30%T/T or100% L/C at sight Seamless steel pipe|API steel pipe
| Item | Details of EN10219 welded steel pipe | |
| Outer Diameter | 1-24 inch | |
| Wall Thickness | 1.8mm----22.2mm | |
| Length | 5m-----16 m Standard & Cut Length | |
| Usage | Line Pipe, Casing And Tubing, Fluid Pipe, Water Delievery, Heating Pipe, Power Pipe, Structure Pipe, Scaffold, Piling Pipe |
|
| Manufacture Processes | Raw material Test→ Uncoiling→ Strip leveling → End Cutting→ End Shearing and Welding→ Accumlator→ Forming→ Telepathy Welding → Seam Heat Treatment→ Air/Water Cooling→ Body/Seam UT→ Sizing Straightening→ Cutting→ Visual and Dimension Inspection→ Hydraulic Test→ End Beveling→ Flatten Test→ Seam/End UT→ Length-Measuring and Weighing→ Coating-Marking→ Storage | |
| Ends Processing | Bevelled or Plain End | |
| Surface Process | 1 Oiled 2 Galvanized 3 3PE Anti-corruption coated 4 According to the sustomers' requirement |
|
| Test Equipment | ||
| Raw Material Test | Tensile Test , Yeild Strength, Elogation, Impact Test, Chemical Analysis, Hardness Test, Charpy Impact Test, Metallographic Examination |
|
| Final Product Test | Hydraulic Test, On-line and off-line Ultrasonic Test, Tensile Test , Yeild Strength, Elogation, Hardness Test, Charpy Impact , Flattening Test Chemical Analysis, Metallographic Examination |
|
| Package | 1 Naked 2 Both ends with a plastic cap , then put the pipe into a bundle covered by plastic cloth accroding to the size of the pipe with steel belt tied 3 According to the sustomers' requirement |
|
| Main Market | Middle East, South and North America, Europe, Asia, Oceania. Southeast Asia | |
