ASTM A530/A530M Seamless Welded Pipes

Home > st2

Seamless and Welded Pipes ASTM A530/A530M

Nominal pipe size

up to 4 = ± 0.79 mm | 5 thru 8 = + 1.58 mm / - 0.79 mm

10 thru 18 = + 2.37 mm / - 0.79 mm | 20 thru 24 = + 3.18 mm / - 0.79 mm

Wall Thickness

All Diameters = - 12.5%

+ tolerance not specified

Length

+ 6.40 mm / - 0 mm

Weight

Weight = + 10% / - 1.5%

Dimensions and Dimensional Tolerances

ASTM A530/A530M Pipe

Units of Measure
American pipe standards use imperial and metric (SI) units for measurement. It is
important not to combine the use of these units since rounding of dimensions has
resulted in an incompatibility between some values.

Dimensions
Standard dimensions for welded and seamless wrought steel pipe for high or
low temperatures and pressures are described in ASME B36.10M. Standard
dimensions for welded and seamless wrought stainless steel pipe are described
in ASME B36.19M. The suffix "S" in the Schedule Number is used
to differentiate B36.19M pipe from B36.10M pipe. ASME B36.10M includes
other pipe thicknesses which are also commercially available with stainless steel material.

Dimensional tolerances
The basic permissible variations, including pipe length and straightness requirements,
are defined in ASTM A530/A530M, this standard being referenced by all ASTM pipe standards.

ASTM pipe astm a 335 gr p22

ASME B36.10M and ASME B36.19M suffix (S)

Other dimensions: NPS 1/2 - 4 \| NPS 16 - 24 Nominal Pipe Size 5 - 14
NPS	5		6		8		10		12		14
O.D.	141.3		168.3		219		273		323.9		355.6
	WT	KG/M	WT	KG/M	WT	KG/M	WT	KG/M	WT	KG/M	WT	KG/M
Sch. 5	2.77	9.46	2.77	11.31	2.77	14.78	3.40	22.61	3.96	31.24	3.96	34.34
Sch. 5S	2.77	9.46	2.77	11.31	2.77	14.78	3.40	22.61	3.96	31.24	3.96	34.34
Sch. 10	3.40	11.56	3.40	13.83	3.76	29.97	4.19	27.79	4.57	35.98	6.35	54.69
Sch. 10S	3.40	11.56	3.40	13.83	3.76	19.97	4.19	27.79	4.57	35.98	4.78	41.36
Sch. 20	-	-	-	-	6.35	33.32	6.35	41.76	6.35	49.71	7.92	67.91
Sch. 30	-	-	-	-	7.04	36.82	7.80	51.01	8.38	65.19	9.53	81.33
STD	6.55	21.77	7.11	28.26	8.18	42.55	9.27	60.29	9.53	73.86	9.53	81.33
Sch. 40	6.55	21.77	7.11	28.26	8.18	42.55	9.27	60.29	10.31	79.71	11.13	94.55
Sch. 40S	6.55	21.77	7.11	28.26	8.18	42.55	9.27	60.29	9.53	73.86	9.53	81.33
Sch. 60	-	-	-	-	10.31	53.09	12.70	81.53	14.27	108.93	15.06	126.72
XS	9.53	30.97	10.97	42.56	12.70	64.64	12.70	81.53	12.70	97.44	12.70	107.40
Sch. 80	9.53	30.97	10.97	42.56	12.70	64.64	15.09	95.98	17.48	132.05	19.05	158.11
Sch. 80S	9.53	30.97	10.97	43.56	12.70	64.64	12.70	81.53	12.70	97.44	12.70	107.40
Sch. 100	-	-	-	-	15.09	75.92	18.26	114.71	21.44	159.87	23.83	194.98
Sch. 120	12.7	40.28	14.27	54.21	18.26	90.44	21.44	133.01	25.40	186.92	27.79	224.66
Sch. 140	-	-	-	-	20.62	100.93	25.40	155.10	28.58	208.08	31.75	253.58
XXS	19.05	57.43	21.95	79.22	22.23	107.93	25.40	155.10	25.40	186.92	-	-
Sch. 160	15.88	49.12	18.26	67.57	23.01	111.27	28.58	172.27	33.32	238.69	35.71	281.72
Other dimensions: NPS 1/2 - 4 \| NPS 16 - 24 Nominal Pipe Size 5 - 14

NPS = Nominal Pipe Size O.D. = Outside Diameter WT = Walltickness KG/M = Kilogram per meter.
Dimensions are in millimeters unless otherwise indicated.
Weights are in kilograms p/meter and approximately given.
