A213 Alloy Steel Pipe

Home > pipearc

A213 ALLOY PIPES

A213 Alloy Tube Chemical Requirements
	C max	Mn max	P max	S max	Si min	Cr max	Ni max	Mo max	Cu Max
T5	0.15	0.3-0.6	0.025	0.025	0.5	4.0-6.0		0.45-0.65
T11	0.05-0.15	0.3-0.6	0.025	0.025	0.5-1.0	1.0-1.5		0.44-0.65
T12	0.05-0.15	0.3-0.61	0.025	0.025	0.50	0.8-1.25		0.44-0.65
T22	0.05-0.15	0.3-0.6	0.025	0.025	0.5-1.0	1.9-2.6		0.87-1.13
T91

Weight Count:(just for Alloy Steel)

Weight(Kg/M)=(OD-WT)*WT*0.02466
OD:Outside Diameter
WT:Wall-Thickness

A213 Seamless Alloy Steel Tube Delivery Condition :
As different requirements,It including pickling,etc. AS per Standard

Packing:
1.Standard Packing
2.Woodbox Packing

Other Test:
1.Hydrostatic or Nondestructive Electric Test
2.Heat Treatment: according to Standard
3.Surface Condition:According to Standard.
4.Grain Size:According to standard
5.Sampling:flattening,flaring,grain size,Marking

More information according the standard:
A213 : Seamless Ferritic and Austenitic Alloy-Steel Boiler,Superheater and Heat-Exchanger Tubes

A213 Alloy Boiler Tube Mechanical Test
	Tensile(Mpa)	Yeild(Mpa)	Elongation(%)	Hardness MAX
T5	415	205	30	89HRB
T11	...	...	...	...
T12	415	220	30	85HRB
T22	...	...	...	...

OTHER GRADES:

High-temperature high-pressure alloy pipe, P11 alloy tube, P5-pressure alloy pipe, P11 high pressure alloy pipe, P22 high pressure alloy pipe, P91 high pressure alloy pipe, T11 high-pressure alloy pipe, T22 high-pressure alloy pipe, T91 high-pressure alloy pipe, A333Gr3 cryogenic tube, A333Gr6 low tube, L245NB pipeline, L290NB seamless, L360NB line pipe, alloy pipe pressure of the modern enterprise:

20G, 20MnG, 25MnG, 15MoG, 20MoG, 12CrMoG, 15CrMoG, 12Cr3MoVSiTiB, 1Cr18Ni9, 1Cr18Ni11Nb, 12Cr2MoWVTiB, 10Cr9Mo1VNb, SA210A1, SA210C, SA213 T11, SA213 T12, SA213 T22, SA213 T23, SA213 T91, SA213 T92, ST45.8 / Ⅲ, 15Mo3, 13CrMo44, 10CrMo910 etc.

High-pressure alloy pipe Material: 10 #, 20 #, 45 #, 20G, 20MnG, 15CrMoG, 12Cr2MoG, 12Cr1MoVG, 12Cr2MoWVTiB, 10Cr9Mo1VNb, SA210A1, SA210C, SA213 T11, SA213 T12, SA213 T22, SA213 T23, SA213 T91, SA213 T92, ST45.8 / Ⅲ, 15Mo3, 13CrMo44, 10CrMo910 etc.
