ASTM A556 carbon steel seamless pipe

Home > pipearc

ASTM A556M-96 "water heater with carbon steel cold drawn seamless pipe."

Name: Seamless Carbon Steel Pipe

Material: SA556MC2.15Mo3.20

Outside Diameter: 16mm-32mm

Wall thickness: 1.3mm-3mm

Length: 3m-12m

Standards: ASTM A556M

Type: Seamless

1 General requirements

Supply of steel in accordance with this standard, except as otherwise provided, shall conform to ASTM A450 / A450M Standard current version of the applicable requirements.

2 grade and chemical composition (%)

Cmax Mn Pmax Smax Si min

Grade A2 0.18 0.27 ~ 0.63 0.035 0.035 -

Grade B2 0.27 0.29 ~ 0.93 0.035 0.035 0.10

Grade C2 0.30 0.29 ~ 1.06 035 0.035 0.10

NOTE: When ordering the standard steel pipe, if the request to add any element other than an element should be excluded from the provisions of the supply.

3 Tensile Properties

MPa yield strength MPa tensile elongation (50mm vertical)%

Grade A2 ≥320 ≥180 ≥35

Grade B2 ≥410 ≥260 ≥30

Grade C2 ≥480 ≥280 ≥30

4 hardness requirements

Grade A2 ≤HRB 72

Grade B2 ≤HRB 79

Grade C2 ≤HRB 89

Sampling Requirements: Take any two steel samples of each batch for testing.

5 size deviation

Outside diameter D <25.4mm 0.1mm

25.4≤D≤31.7mm 0.15mm

Wall thickness of 0 to + 20%

6 surface accuracy and appearance

Pipe should not have iron oxide;

Pipe should be fairly straight, and should have a smooth tube ends without burr;

Pipe should have a finished surface, there should not be removed to allow the wall thickness tolerances in the range of surface defects.

7 flattening test

The method according to ASTM A450 regulations, the number of samples and requirements: either take a batch of steel. Take the cut at both ends of a sample for testing.

8 flaring test

The method according to ASTM A450 regulations, the number of samples and requirements: either take a batch of steel. Take the cut at both ends of a sample for testing is www.steelpipechn.com.

9 NDT

Provisions should be standard ASTM A450, after the last cold drawn by root after the final heat treatment after non-destructive testing.

10 Delivery Status

Heat treatment, final cold drawing should be carried out after the heat treatment at higher temperature or 640 ℃.

11 mark

Including plant name and the purchase order number, standard number, grade and size, the demand side is specified, the bar code can be used as a supplement to sign.

If you are interested in us such tubes, such tubes would like to order, please give me a message.

There are problems also can leave a message and communicate with me. Stuff, make friends.
