A500 STEEL PIPE

Home > st2

CHARACTERISTICS

A500 steel pipes can be subjected to most of the usual fabricating operations. Ductility is good. It bends well, flattens, cuts, punches, flares and flanges easily, and can be welded by the commonly-used techniques and practices.

APPLICATIONS

Common uses for ASTM A500 pipe include hand rails, posts, storage racks, displays, furniture, etc.

A500 STEEL PIPE

SIZES

Pipe Size	OD (inches)	Schedule 10	Standard	Schedule 40	XH	Schedule 80
¾”	1.05	X	X	X
1”	1.315	X	X	X
1 ¼”	1.66	X	X	X	X	X
1 ½”	1.9	X	X	X	X	X
2”	2.375	X	X	X	X	X
2 ½”	2.875	X	X	X	X	X
3”	3.5	X	X	X	X	X
3 ½”	4	X	X	X	X	X
4”	4.5	X	X	X	X	X
5”	5.563		X	X	X	X
6”	6.625		X	X	X	X
8”	8.625		X	X	X	X
10”	10.75		X	X	X
12”	12.75		X	X	X
14”	14	X	X		X
16”	16	X	X		X
18”	18	X	X		X
20”	20	Available in schedules 10, 20 and 30.

TYPICAL MECHANICAL PROPERTIES

	Grade B	Grade C
Tensile Strength, Min psi	58,000	62,000
Yield Strength, Min psi	46,000	50,000
Elongation in 2” Min	23%*	21%**
*.180” wall and over
**.120” wall and over

TYPICAL CHEMICAL PROPERTIES

	Grade B	Grade C
Carbon, Max %	0.260	0.230
Manganese, Max %	----	1.350
Phosphorus, Max %	0.035	0.035
Sulphur, Max %	0.035	0.035
Copper, when copper steel is specified, Min %	0.200	0.200
