din 1629 st52 pipe,St37.0 seamless pipe,St44.0 pipe

DIN 1269 seamless pipe

Sizes (O.D. x W.T): from 13.7mm -- 812.8mm x 1.5mm to 60mm
Standard: DIN1269
Steel Grade: St37, St44, St45, St52

din 1629 st52 pipe

din 1629 st52 pipe,



  DIN1629 pipe Mechanical Properties

Grade Yield Strength
(Mpa)
Tensile Strength
(Mpa)
Elongation
(%)L
Elongation
(%)T
DIN1629 ST37.0 ≥235 350-480 25 23
DIN1629 ST44.0 ≥275 420-550 21 19
DIN1629 ST52.0 ≥355 500-650 21 19


Delivery Condition:

  • Heat treatment,Annealed, Normalized, Normalized and Tempered

Surface treatment:

  • Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
  • Painting as requested.

Chemical Compositions(%) of DIN1629

Grade C Si Mn P S
DIN1629 ST37.0 ≤0.17 / / ≤0.040 ≤0.040
DIN1629 ST44.0 ≤0.21 / / ≤0.040 ≤0.040
DIN1629 ST52.0 ≤0.22 ≤0.55 ≤1.70 ≤0.040 ≤0.035

din 1629 St37.0 seamless pipe,din 1629 St44.0 pipe
