Epoxy coal tar coating pipe

Product Description

-A two pack epoxy-coal anticorrosive coating and it is characterized by good adhesion and excellent resistance to corrosion and water.

-VOC less than 180g/L

Intended Uses

-For use in steelwork of the dock and bridge under water to anticorrosive primer.

-For use in the exterior of plumber of city establishment such as tap water and natural gas pipeline.

-For use in the surface of beton construction to corrosion.

-For use in the part under water line to anticorrosive primer.

Product Information

Volume Solids

78%±2%

Finish/Sheen

No Suited

Typical Film Thickness

80 microns dry (110microns wet)

Theoretical Coverage

9.1m2/L at typical film thickness

Mix ratio

13:1(volume)20:1(mass)

Method of Application

Airless Spray

No Recommended

Air Spray

No Recommended

Brush/Roller

Recommended

Thinner

Not recommended. Use only in exceptional circumstances (volume 5%)

Cleaner

HX-501

Induction Period

20min

Drying Information

10°C

25°C

35°C

Touch Dry

4h

2h

1h

Hard Dry

48h

24h

12h

Pot Life

  4h

2h

1h

Overcoating Data         Substrate Temperature

Overcoated by

10°C

25°C

35°C

Min Max

Min Max

Min Max

725-H57-08

48h 10d

24h  7d

12h  5d

Storage

Store in cool and dry conditions. Well ventilate. Keep away from hot and fire. Shelf Life: 12 months minimum at 25°C. Subject to re-inspection thereafter

Pack Size

Part A

22kg/13L in 20L container

Part B

1.1kg/1L in 6L container

Flash Point

Part A

Greater than 31°C

Part B

Greater than 29°C

Mixed paint

Greater than 31°C

Systems and

Compatibility

Consult your Sunrui Representative for the systems best suited for the surfaces to be protected.

Surface Preparation

Remove loose powder of the cement, attached organisms, mud, oil or grease and other foreign matter thoroughly, and oil can be cleaned by scour.
