ASTM A106 GR.B/ A106 GR.C High Temperature Seamless Carbon Steel Pipe for pipeline
ASTM A106 High Temperature Seamless Carbon Steel Pipe
ASTM A 106/A 106 M ASTM A106 GR.B/ A106 GR.C Standard Specification for High-Temperature Seamless Carbon Steel Pipe

Standard
Grade
Chemical Composition (%)
Mechanical Properties
C%
Si%
Mn%
P,S%
Cr%
Mo%
Ni%
Cu%
V%
Tensile Strength(Mpa)
Yield Strength(Mpa)
ASTM A106
GR.A
Not more than 0.25%
Not less than 0.10%
0.27-0.93%
Not more than 0.035%
Not more than 0.40%
Not more than 0.15%
Not more than 0.40%
Not more than 0.40%
Not more than 0.08%
Not less than 330
Not less than 205%
GR.B
Not more than 0.30%
Not less than 0.10%
0.29-1.06%
Not more than 0.035%
Not more than 0.40%
Not more than 0.15%
Not more than 0.40%
Not more than 0.40%
Not more than 0.08%
Not less than 415
Not less than 240
GR.C
Not more than 0.35%
Not less than 0.10%
0.29-1.06%
Not more than 0.035%
Not more than 0.40%
Not more than 0.15%
Not more than 0.40%
Not more than 0.40%
Not more than 0.08%
Not less than 485
Not less than 275

Application: It truly is used for the machining for bending, border-coiling and comparable shape-forming.

Principal Steel Tube Grade: A106 GR.A, A106 GR.B, A106 GR.C and so forth. Other grade also can be provided soon after consulting with clients.


This specification covers carbon steel seamless pipe for high-temperature service in NPS 1?eight to NPS 48 [DN 6 to DN 1200] inclusive, with nominal (typical) WT as given in ASME 36.10M. It shall be allowable to furnish pipe obtaining other dimensions supplied such pipe complies with all other needs of this specification. seamless tube ordered beneath this specification shall be appropriate for bending flanging, and equivalent forming operations, and for welding. When the steel would be to be welded, it is presupposed that a welding procedure appropriate towards the grade of steel and intended use or service are going to be utilized.
